Intergraph CADWorx fieldPipe Professional when combined with Intergraph CADWorx Plant Professional, delivers the most powerful as-built and spool verification tool on the market.


Laser Precision Accuracy

By adding CADWorx fieldPipe Professional to CADWorx Plant Professional,CADWorx fieldPipe leverages the power of intelligent plant design and Leica’s Total Station precision laser technology to create as-builts quicker and more accurately than ever before.


Quicker, Easier and Safer As-builts

Model hundreds of piping components quickly and easily while in the field, from only a few locations. Site work is made safer by reducing the climbing and clambering normally associated with producing as-builts for existing piping systems.


Point-and-Shoot Component Placement

Creating CADWorx fieldPipe as-built models in the field is easy; set up the Total Station, point the laser at a piping item and pick components from the toolbar. Presto! The component is placed in the model at the exact location.


As-builts from Point Clouds

With CADWorx fieldPipe users can rapidly create intelligent as-built models directly from scanned plant data. As-built pipe can be routed by selecting just a single point on a pipe run, thereby cutting out hundreds of time-consuming steps in the as-built creation process.


Piping, Steel and Equipment

The combination of CADWorx fieldPipe and CADWorx Plant Professional offers full piping, equipment, steel, ducting, cable trays, model review and walkthrough modeling capabilities.


Design Directly in the Field

CADWorx fieldPipe is capable of capturing tie-in points in the field. This allows operators to design clash-free piping systems without leaving the site.


Spool Verification

CADWorx fieldPipe can also be used to accurately verify piping spools in the shop and, by locating them into the as-built model, guarantee accurate field-fit before spools are even shipped to the site.


Piping Specifications

Through CADWorx Plant Professional, CADWorx fieldPipe has access to over 60,000 ready-to-go components from metric, metric/inch and imperial specifications.


Automatic Isometrics

Isometrics from single or multiple pipe runs can be created quickly and automatically from your CADWorx fieldPipe models.


Links to Stress Analysis

Models created using CADWorx fieldPipe can leverage the bi-directional links between CADWorx Plant Professional and Intergraph® CAESAR II®, giving total accuracy from the field to analysis.


The Power of Leica CloudWorx™

Both CADWorx fieldPipe and CADWorx fieldPipe Professional include Leica CloudWorx Professional for CADWorx fieldPipe.

Note: CADWorx fieldPipe is a supplemental package to CADWorx Plant Professional and requires CADWorx Plant Professional to deliver all of these features.
